What is the structure of the hollow rotating platform and what is the Haibo tooth hollow rotating platform?

What is the structure of the hollow rotating platform?

The hollow rotating platform mainly includes the following structures:

1. Turntable: The turntable of the hollow rotating platform is a hollow structure, which facilitates the installation of air pipes and wires in the fixture.

2. Support structure: The rotating platform can be equipped with a servo motor or a stepper motor, and can achieve positioning at any angle through high-precision gear transmission.

3. Drive system: The hollow rotating platform can be driven by a motor to realize automatic angle adjustment.

4. Other structures: The hollow rotating platform may have other structures, such as customized input flange, input shaft hole, etc., to flexibly change the interface size, and can be matched with any brand of servo motor or stepper motor.

What is the Haibo Teeth Hollow Rotating Platform?

Hypotooth hollow rotating platform, also known as hollow rotating table, hypoid reducer, altitude gear reducer, etc., is a high-precision, high-rigidity, cost-effective rotating device, mainly used for large plate diameters, Rotary designs with large inertia and rapid positioning are also widely used in automotive transmission systems, CNC equipment, robotic arms and other industries.

Its structure usually uses a single-stage spiral gear reduction method to increase the output torque. The gear accuracy level can reach below level 5. At the same time, it is equipped with a flexible backlash adjustment mechanism to control the backlash by adjusting the center distance between the two gears., resulting in extremely small backlash of the rotating platform, and the repeatable positioning accuracy is less than 5 arc minutes. The turntable of the rotating platform is supported by a set of precision crossed roller bearings in which the rollers are arranged staggered at 90 degrees.
