VRS European High Precsion High Torque Right Angle Planetary Gearbox

With the feature of high precision, and it is a ideal solution for higher levels of positional accuracy

The use of uncaged needle roller bearings can realize the high rigidity and high torque

Can be attached to any motor all over the worldwith the adapter-bushing connection

No grease leakagewith the high viscosity anti-separation grease

Can be matched withservo motor and stepper motor

Inquiry Now

Drawings Download

3D model download

Introduction

Specification Table

Download

Product Description

VRS European series high-precision high-torque planetary reducer has the following characteristics:

1.With high precision, it is an ideal solution for higher level positioning accuracy

2.Using cageless needle bearings can achieve high rigidity and high torque

3.Can be installed on any motor in the world through adapter bushing connection

4.Using high viscosity anti-separation grease, no grease leakage

5.Can be matched with servo motors and stepper motors

VRS can provide 9 machine base specifications; backlash is 3 arc minutes; maximum torque can reach 1200NM; maximum radial load capacity is 12400N; can provide 4:1 to 1000:1 transmission ratio; can be connected to any type of motor; working life is about 20,000 hours.

VRS series precision planetary gear reducer is suitable for a variety of industries and uses, including: printing and paper processing; CNC machine tool processing equipment; military and aerospace equipment; semiconductor wafer manufacturing; coating and film processing; high-speed electronic assembly; injection molding, packaging; CNC plasma flame cutting equipment; automated packaging equipment, printing machinery.

Model No.	Unit	Stage	Ratio	VRS060	VRS075	VRS100	VRS140	VRS180	VRS210	VRS240
Rated Output Torque	Nm	1	3	55	130	208	342	586	1140	1500
			4	50	140	290	542	1050	1700	2500
			5	60	160	330	650	1200	2000	2500
			6	55	150	310	600	1100	1900	2260
			7	50	140	300	550	1100	1800	2300
			8	45	120	260	500	1000	1600	2100
			9	40	100	230	450	900	1500	1800
			10	40	100	230	450	900	1500	1800
		2	15	55	130	208	342	586	1140	2300
			16	55	130	208	342	586	1140	2300
			20	50	140	290	542	1050	1700	2500
			25	60	160	330	650	1200	2000	2500
			28	60	160	330	650	1200	2000	2500
			30	55	150	310	600	1100	1900	2300
			35	50	140	300	550	1100	1800	2200
			40	45	120	260	500	1000	1600	2350
			50	60	160	330	650	1200	2000	2200
			70	50	140	300	550	1100	1800	2200
			100	40	100	230	450	900	1500	1800
Max. Output Torque	Nm	1,2	3-100	3 Times of Normal Output Torque
Rated Input Speed	Rpm	1,2	3-100	5000	4000	4000	3000	3000	2000	1000
Max. Input Speed	Rpm	1,2	3-100	10000	8000	8000	6000	6000	4000	2500
Micro Backlash P0	Arcmin	1	3-10	≤1	≤1	≤1	≤1	≤1	≤1	≤1
Micro Backlash P0	Arcmin	2	12-100	≤3	≤3	≤3	≤3	≤3	≤3	≤3
Precision Backlash P1	Arcmin	1	3-10	≤3	≤3	≤3	≤3	≤3	≤3	≤3
Precision Backlash P1	Arcmin	2	15-100	≤5	≤5	≤5	≤5	≤5	≤5	≤5
Torsional Rigidity	Nm/arcmin	1,2	3-100	7	14	25	50	145	225	260
Max. Radial Force	N	1,2	3-100	2750	4100	6400	9880	15000	20000	27500
Max. Axial Force	N	1,2	3-100	2350	3200	5360	9690	14200	28000	30000
Service Life	Hr	1,2	3-100	20000hrs
Efficiency	%	1	3-10	≥96%
Efficiency	%	2	15-100	≥93%
Weight	Kg	1	3-10	1.8	3.8	7.2	16.8	32	49	65
Weight	Kg	2	15-100	2.1	4.1	8.1	17.5	35	53	70
Operating Temperature	℃	1,2	3-100	（-15℃~+90℃）
Lubrication		1,2	3-100	Synthetic Grease
Protection Class		1,2	3-100	IP65
Mounting Position		1,2	3-100	Any Direction
Noise Level	dB(A)	1,2	3-100	≤62	≤62	≤65	≤68	≤68	≤70	≤70

Moment of Inertia

Model No.	Unit	Stage	Ratio	VRS060	VRS075	VRS100	VRS140	VRS180	VRS210	VRS240
Moment of Inertia	kg.cm2	1	3	0.16	0.61	3.25	9.21	28.98	69.61	82.16
			4	0.14	0.48	2.74	7.54	23.67	54.37	75.58
			5	0.13	0.47	2.71	7.42	23.29	53.27	75.29
			6	0.13	0.45	2.65	7.25	22.75	51.72	72.35
			7	0.13	0.45	2.62	7.14	22.48	50.97	69.13
			8	0.13	0.44	2.58	7.07	22.59	50.84	69.22
			9	0.13	0.44	2.57	7.04	22.53	50.63	66.23
			10	0.13	0.44	2.57	7.03	22.51	50.56	66.23
		2	15-40	0.03	0.13	0.47	2.71	7.42	23.29	48.23
		2	50-100	0.03	0.13	0.44	2.57	7.03	22.51	45.58
